| Item/Series | BL02 LC series | BL03 PB series | BL04 LB series | BL05 KB series | BL07 XC series | BL09 YX series | BL10 XF series |
| IC card | ○ | ○ | ○ | ○ | ○ | ○ | ○ |
| China UnionPay card self-service payment | ○ | —— | —— | ○ | ○ | ○ | ○ |
| Coin-operated self-service payment | —— | —— | —— | —— | —— | ○ | ○ |
| Ticket printer | ○ | ○ | ○ | ○ | ○ | ○ | ○ |
| Voice broadcast | ○ | —— | —— | ○ | ○ | ● | ● |
| Emergency stop switch | ● | —— | —— | ● | ● | ● | ● |
| Domestic flow meter | ● | ● | ● | ● | ● | ● | ● |
| Imported flow meter | —— | —— | —— | —— | —— | ○ | ○ |
| Domestic fuel dispensing nozzle | ● | ● | ● | ● | ● | ● | ● |
| Imported fuel dispensing nozzle | ○ | —— | —— | ○ | ○ | ○ | ○ |
| Metal keyboard | ○ | ○ | ○ | ○ | ○ | ● | ● |
| Breakaway valve | ○ | —— | —— | ○ | ○ | ○ | ○ |
| Variable frequency control | ○ | —— | ○ | ○ | ○ | ○ | ○ |
| Solenoid valve | ● | ● | ● | ● | ● | ● | ● |
| Fuel vapor recovery system | ○ | —— | —— | ○ | ○ | ○ | ○ |
| Stainless steel housing | —— | —— | —— | ○ | —— | ○ | —— |
Symbol description
Standard configuration●
Optional configuration○
Without this configuration——
Our company provides a detailed fuel dispenser base installation diagram for filling stations and other fuel enterprises according to the type of fuel dispensers being installed. By virtue of our rich experience and advanced technologies, we can help reduce your investment cost and operation risk.
Beilin is able to help customers select the most suitable fuel pump based on their practical application and budget.
For a customer seeking low cost investment and is willing to set up a filling station with only a small quantity of fuel dispensers, we suggest self-priming pumps. If you want to build a filling station with large quantity of fuel dispensers, it is more wisely to use submersible pumps. We advise you to decide what kind of fuel pump you want before you construct the filling station because it will be difficult to replace self-priming pumps with submersible pumps after the filling station has been constructed.
Our fuel dispensers can work with fuels that include gasoline, alcohol, jet fuel, diesel, kerosene, biodiesel, and avgas.
Fuel type
It is important to select fuel dispensers with proper quantity of dispensing nozzles based on your specific operation environment and the passenger flow volume of your filling station. We have fuel dispensers with 1, 2, 4, 6 or 8 (submersible pump) nozzles for you to select. If you are not sure how many fuel dispensing nozzles you need, just tell us about your usage needs, then we can help you make an analysis and recommend you fuel dispensing machines with the optimal quantity of nozzles.
